Technical Specifications
| Model | ACF6 |
|---|---|
| Tank Size (Pressure Vessel) | 14” × 65”, 2.5” Top Opening |
| Flow Rate | Up to 6.0 m³/1.5h |
| Working Pressure | Minimum: 1.8 Kg/cm² Maximum: 3.5 Kg/cm² |
| Filter Media | Activated Carbon – 60 Kg Coarse Silex – 15 Kg |
| Inlet, Outlet & Drain Fitting | 1″ |
| Electric Supply Requirement | 230VAC, 6 AMP |
| Process Valve | Fully Programmable Automatic Valve powered by 12VDC / 1.5 AMP Adaptor |
| Outlet Chlorine | Nil |
| Outlet Color & Odor | Nil |
“`
